Weighing Packaging Machine with 10 Heads Weigher CB-VP62
Feature
1. Film drawing down system controlled by servo.
2. Famous brands of electrical and pneumatic components, such as SIMENS PLC, SIMENS servo, SMC pistons, SCHNEIDER switches.
3. Various alarm system to reduce wasting rate.
4. Removable electrical panel. All the doors can be opened.
5. Easy to operate, low maintenance.
6. It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.
7. The Way of Bag Making: The machine can make pillow bag and gusseted bag, or according to customer’s requirements.
Parameter
|
Packaging Machine |
|
|
Items |
Contents |
|
Packing Speed |
Max. 60 bags / min ( for empty bag making) |
|
Bag Size |
(L) 100-400mm (W) 115-300mm |
|
Bag Type |
Pillow-type bag, gusseted bag |
|
Range of Measuring |
≤ 6.8L |
|
Range of Film Roll |
250-620mm |
|
Film Thickenss |
0.04-0.09mm |
|
Air Consumption |
0.8Mpa 0.3cmb / min |
|
Power |
3.9 KW / 220V 50-60Hz |
|
Dimension |
(M) 1620 × (W) 1300 × (H)1780mm |
|
Weight |
800kg |
|
Combination Weigher |
||
|
Weigher |
10 Heads combination weigher |
14 Heads combination weigher |
|
Surface Execution |
Plain surface / dimple surface |
Plain surface / dimple surface |
|
Material |
304 stainless steel |
304 stainless steel |
|
Bucket capacity |
2.5L |
2.5L |
|
Max Single Dump |
5L |
5L |
|
Max Speed |
Up to 57-61 wpm (The weight less than 150g) |
Up to 85-90 wpm (The weight less than 150g) |
|
Discharge Point |
One |
One |
|
Accuracy |
± 1g ( The weight less than 100g ) |
± 1g ( The weight less than 100g ) |
|
Control Panel |
7 inch touch screen |
10 inch touch screen |
|
Driving System |
Step motor |
Step motor |
Optional
14 Heads Weigher
Finished Product Conveyor
Round Turn Table
Z Type Conveyor
10 Heads Weigher
Incline Conveyor
