Rotary Premade Pouch Packaging Machine with Auger Filler CB-200B
INQUIRY
Feature
- Packing Weight: 10-5000G (The screw attachment is to be changed)
- Weighing Range: 1-6000G (Resolution is 01g)
- Filling Accuracy:
- Package Weight ≤ 100g, with an error ≤ ±0.5-1g
- Package Weight: 100~1000g, with an error ≤ ±0.3-1%
- Package Weight: ??1000g, with an error ≤ ±0.25-0.5%
- Filling Rate: 10—50bags / min
- Power Supply: 3P / 380V (1P / 220V according your requirement) 50-60Hz
- Total Power: 1.9KW
- Total Weight: 250KG
- Overall Dimensions: 800 × 1100 × 2150MM
- Hopper Volume: 50L
Parameter
| Model | CB8-200B |
|
Working Position |
Eight-working position |
|
Pouch Material |
Laminated film |
|
Pouch Pattern |
Stand-up & zipper pouch、flat pouch |
|
Pouch Size |
W: 100-210mm L: 100-350mm |
|
Speed |
10-45pouches / min (The speed depends on the product status and flling weight) |
|
Weight |
1000KGS |
|
Voltage |
380V 3phase 50HZ / 60HZ |
|
Total Power |
4KW |
|
Compress Air |
0.6m3 / min (supply by user) |
Optional
Auger Filler
Finished Product Conveyor
Round Turn Table
Screw Conveyor
