Liquid Packaging Machine with Liquid Pump CB-VP42
INQUIRY
Feature
1. The packing machine matched with liquid pump or paste pump, can pack different liquid or cream automatically. The whole system is linkage control, automatic feeding, stop working without materials.
2. The contact parts with food is made of 304# or 316# high quality stainless steel steel ensure food safety.
3. High automatic, it can complete the whole packaging process, measuring, filling , sealing, date printing , counting, transporting.
4. Famous brands of electrical and pneumatic components, such as SIMENS PLC, SIMENS servo, SMC pistons,SCHNEIDER switches.
5. The Way of Bag Making: The machine can make pillow bag and gusseted bag, or according to customer’s requirements.
Parameter
| Packaging Machine | |
| Items | Content |
| Packing Speed | 50-60bags / min |
| Bag Size | (L) 50-330 mm (W) 50-200 mm |
| Bag Making Mode | Pillow-type bag, standing bag, bag with euroslot |
| Range of Measuring | ≤2.4L |
| Max Packaging Film Width | 420 mm |
| Thickness of Film | 0.04-0.09 mm |
| Air Consumption | 0.8 Mpa 0.3 cmb / min |
| Main Power / Voltage | 2.2 KW / 220V 50 Hz |
| Dimension | L1458 * W920 * H1392 mm |
| The Weight of Switchboard | 480 kg |
| Liquid / Paste Pump | |||
| Item | Small type filling machine | Middle type filling machine | Large type filling machine |
| Filling Range | 30-250ml | 100-1000ml | 1000-3000ml |
| Capacity | 10-30bags / min | 8-25bags / min | 6-20bags / min |
| Accuracy | ±0.5% | ±1% | ±1% |
| Power / Voltage | 220V 50HZ | 220V 50HZ | 220V 50HZ |
Optional
Paste Pump
Finished Product Conveyor
Round Turn Table
Liquid Pump
