    High Speed VFFS Packaging Machine CB-VG42A
    High Speed VFFS Packaging Machine CB-VG42A

    Feature

    • Low cost high gain, high speed and efficiency.
    • Famous brand PLC control system, large touch screen, convenient to operate.
    • Film drawing down system and horizontal sealing controlled by servos.
    • It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.
    • The Way of Bag Making: The machine can make pillow-type bag and standing bag according to customer’s requirements.

    Parameter

    Items

    Content

    Packaging Speed

    Max 120 bags / min (Specific speed depends on bag length, film material, product, etc.)

    Bag Size

    (L) 50-360 mm (W) 50-200 mm

    Bag Making Mode

    Pillow type bag and gusset bag

    Range of Measuring

    ≤ 2.4L

    Max Packaging Film Width

    420 mm

    Thickness of Film

    0.04-0.09 mm

    Air Consumption

    0.8 Mpa 0.3 cmb / min

    Main Power / Voltage

    5.6 KW / 220V 50 Hz

    Dimension

    L1850 * W1200 * H1460 mm

    The Weight of Switchboard

    500 kg

    Optional

    14 Heads Weigher

    14 Heads Weigher

    Finished Product Conveyor

    Finished Product Conveyor

    Round Turn Table

    Round Turn Table

    Z-Type Conveyor

    Z-Type Conveyor

    Platform

    Platform
