10 Heads Powder Weighing Filling Packaging Machine CB-VP42

INQUIRY

    10 Heads Powder Weighing Filling Packaging Machine CB-VP42
    10 Heads Powder Weighing Filling Packaging Machine CB-VP42

    Feature

    1. Low cost high gain, high speed and efficiency.

    2. Famous brands of electrical and pneumatic components, such as SIMENS PLC, SIMENS servo, SMC pistons, SCHNEIDER switches.

    3. Film drawing down system controlled by servo motor.

    4. Minimize the loss with complete automatic warn protection function.

    5. It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.

    6. The Way of Bag Making: The machine can make pillow-type bag and standing bag according to customer’s requirements.

    Parameter

    Packaging Machine

    Items

    Contents

    Packing Speed

    50-60bags / min

    Bag Size

    (L) 50-330 mm (W) 50-200 mm

    Bag Making Mode

    Pillow-type bag, standing bag, bag with euroslot

    Range of Measuring

    ≤2.4L

    Max Packaging film Width

    420 mm

    Thickness of Film

    0.04-0.09 mm

    Air Consumption

    0.8 Mpa 0.3 cmb / min

    Main Power / Voltage

    2.2 KW / 220V 50 Hz

    Dimension

    L1458 * W920 * H1392 mm

    The Weight of Switchboard

    480 kg

    Combination Weigher

    Weigher

    10 Heads combination weigher

    14 Heads combination weigher

    Surface Execution

    Plain surface / dimple surface

    Plain surface / dimple surface

    Material

    304 stainless steel

    304 stainless steel

    Bucket Capacity

    1.3L

    1.3L

    Max Single Dump

    2.5L

    2.5L

    Max Speed

    Up to 57-61 wpm (The weight less than 150g)

    Up to 85-90 wpm (The weight less than 150g)

    Discharge Point

    One

    One

    Accuracy

    ± 1g ( The weight less than 100g )

    ± 1g ( The weight less than 100g )

    Control Panel

    7 inch touch screen

    10 inch touch screen

    Driving System

    Step motor

    Step motor

    Optional

    14 Heads Weigher

    14 Heads Weigher

    Finished Product Conveyor

    Finished Product Conveyor

    Round Turn Table

    Round Turn Table

    Z Type Conveyor

    Z Type Conveyor

    10 Heads Weigher10 Heads Weigher
