    Liquid Filling and Packaging Machine CB-VPZ52

    Feature

    1. The 90??spare parts is made of stainless material, exposed electric equipment use IP6 waterproof standard, in a humid environment, still can stable operation, and keep new for a long time.

    2. Adopted with a swing arm type rubber roller traction tension membrane (servo motor driver), and has the function of automatic adjustment.

    3. Advanced design ensures that the series packing machine is suitable for different industries, when use adjustment, operation, maintenance is very convenient.

    4. The upper and lower adjustable film pulling method, to adapt to the different length of bag, material and capacitance.

    5. Material testing photocell can be detected through the thin film material, can accurately give feedback information to full of packaging process.

    6. Horizontal sealing dynamic design have two optional device that cylinder power and servo fast transverse sealing.

    7. The vertical sealing structure using a new type of screw to adjust to different specifications.

    Parameter

    Packing Machine

    Model

    CB-VZ82

    CB-VPZ52

    Max Packing Speed

    Max 30bags / min

    Max 30baas / min

    Film Wide Range

    360mm-820mm

    160mm-520mm

    Bag Size

    (L) 180-520mm (W) 180-410mm

    (M) 120mm-350mm (W) 80mm-250mm

    Bag Type

    4 Sides sealing bag

    Pillow bag

    Film Thickness

    0.04-0.09mm

    0.04-0.09mm

    Air Consumption

    0.8Mpa 0.5cmb / min

    0.8Mpa 0.5cmb / min

    Power Supply

    6.7KW 220V 50 / 60HZ

    3.4KW 220V 50 / 60HZ

    Dimension

    (L)1920 x (W)1860 x (H)2500mm

    (L) 1610x (W) 1460 x (H) 2340mm

    Weight

    850kg

    560kg

    Liquid / Paste Pump

    Item

    Small type filling machine

    Middle type filling machine

    Large type filling machine

    Filling Range

    30-250ml

    100-1000ml

    1000-3000ml

    Capacity

    10-30bags / min

    8-25bags / min

    6-20bags / min

    Accuracy

    ±0.5%

    ±1%

    ±1%

    Power / Voltage

    220V 50HZ

    220V 50HZ

    220V 50HZ

    Optional

    Paste Pump

    Paste Pump

    Finished Product Conveyor

    Finished Product Conveyor

    Round Turn Table

    Round Turn Table

    Liquid Pump

    Liquid Pump
